WILDCAT
FULL SUSPENSION STEP-THRU ELECTRIC BIKE.
WILDCAT SPECS.
-
Type: Full Suspension Frame.
Material : Alloy 6061
Integration: Motor and Battery Integrated Frame.
Artwork: High quality enamel gloss with anti-rust treatment .
Colour: Military Green
EU Frame safety standard-tested : EN1519
-
Bafang MM G332.250. 48V/250W UART
Torque : 80nM. 9 levels of Pedal assist (PAS). Average speed 32km/h.
Torque sensor ( Cadence Torque ) AND Pedal assist functionality.
Motor is Protected inside the frame from outdoor elements - salt air , water splash , rain , mud ,direct sunlight and rocks or other objects during riding.
Motor / Ride Fine-tuning : Fully reprogrammable parameters - configure to your own riding preferences. Adjust settings to power, speed , pedal assist ( each of the 9 levels of PAS may be adjusted ) . Connect to your computer and adjust Via a programming tool to suit each riders style and preferences.
-
EEL li ion battery is automatically locked-In to the frame down-tube when inserting it.
Removable when unlocking it with a key ( Duplicate keys are included).
Battery specs ;Panasonic Li ion 18-650 cells 35E 3500 mah 48v 14aH ( 672wH ).
Average Range : 100km on medium level PAS .
-
Front Air Shocks : 29” RST Blade ebike
specific
Rear air shock: Suntour ebike specific.
Rims : XC Comp Double-wall strength CS 28" x 36 holes /36spokes
Hubs: Solon 32 holes . Chromoly body with Sealed bearings.
Tyres : 29* x 2.10" Tube Chaoyang Tubeless
Seat post : Chilled Squirrel
Saddle: RockBros Memory foam comfort .
Cassette: Shimano 10 Speed Deore Shadow Plus 11-42T
Rear Derailleur: Shimano Deore Shadow Plus 10 speed
Gear Shifter : Shimano 10 speed Rapid Fire
Brakes: Tektro Hydraulic E-brakes Disc with e-brake cut off Safety.
Rotors: Tektro Front wheel 180mm / Rear wheel 160mm.
Pedals: Wide platform
Handlebar : MTB riser handlebar
Stem: Chilled Squirrel
Grips: Silicon comfort
* Please Note : We are continuously looking for ways to improve performance based on the availability of improved components and technologies therefore mechanical specs may change without prior notice with the aim of improving overall performance.
-
Riders Height 1.50-1.60 : 15"
Riders Height 1.60-1.70m : 17”
TOUGH REINFORCED ALLOY 6061 FRAME WITH LIFE-TIME WARRANTY.
INTEGRATED REMOVABLE REAR CARRIER.
COLOUR LCD DISPLAY. 5 LEVELS OF PAS. USB CONNECTIVITY FOR CHARGING DEVICES.
COMFORT MEMORY FOAM SADDLE.
tektro hydraulic e-brakes
Tektro’s Market-leading Dual piston-Power brake system integrated with Wildcat’s mid drive system.
E-bike Safety Cut-Off sensor for dynamic stopping power.
what else comes with wildcat?
comfort saddle.
E-bike Riding Comfort.
Memory foam saddle.
3 WATERBOTTLES + 2 CARTRIDGES.
Easily attach your C02 cartridges and water bottles for your longer trips.
ADJUSTABLE SITTING POSITION.
Ebike Riding comfort.
Adjustable handlebar stem to find your perfect sitting position.
LOW MAINTENANCE.
Reduce Wear and Tear. Avoid chain breaks.
E-bike drive systems need to perform at high torque levels.
ebike chain wax helps make a smoother ride with less wear and tear.
ANTI-CORROSION.
Ensure your Ebike is Corrosion-free.
DONT TOUCH MY EBIKE!
Alert you to anyone fiddling with your ebike.
DETER THIEVES.
Tough Cable Combination Lock.
1.5cm thick cable.
wildcat 2024 early bird pre-order Schedule.
Early Bird electric bike pre-orders streamlines the supply chain.
A unique Limited edition collection of electric bikes is launched Annually.
Delivering Superior E-biking Value and substantial Savings.
E-bike Satisfaction Guarantee.
A Risk-Free Electric bike investment for you.
Our Mission is to help you find an e-bike that suits you.
And for any reason you are not happy you get a Full refund.
Just let us know within 48 hours of receiving your e-bike.
